In this post, we will explore how the B instruction is used for branching, along with practical examples. The B instruction unconditionally moves the execution flow to a specified location, forming the foundation for conditionals, loops, and broader program structure.

Youtube Video to explain ARM B instruction
youtube.com/@seojuncha

Why Do We Use the B Instruction?

The B instruction simply moves the execution flow to another position. It does not return like a function call; its behavior is similar to the goto statement in C.

Typical uses include:

  • Implementing loops
  • Skipping specific code blocks
  • Simple control flow switching

How Execution Flow Branching Works

The CPU stores the address of the next instruction in the Program Counter (PC). A branch instruction changes the PC to another address, altering where the CPU fetches the next instruction.

Note: In ARMv4’s pipeline, the PC appears as current instruction address + 8 bytes. However, the assembler handles branch offset calculation, so this does not affect typical coding.

Branch Instruction: B

b label

b label simply jumps to the address indicated by the label. Internally, this is equivalent to updating the PC with the label’s address.

Understanding Labels

A label gives a name to a specific instruction address.

  label:
    instructions

A colon (:) must be placed after the label name. The label’s address is the address of the first instruction below it.

Example:

  foo:
    mov r0, #1   @ address = 0x10000
    mov r0, #2   @ address = 0x10004

Here, the address of foo is 0x10000.

Example Code

  .text
  .global _start
_start:
  mov r0, #2
  b   foo
  mov r1, r0     @ never executed
foo:
  add r0, r0, #3
  b   _start

Execution Flow

  1. mov r0, #2
  2. b foo → jumps to foo
  3. add r0, r0, #3
  4. b _start → jumps back to _start
  5. executes again

Thus, the value of R0 repeats as 2 → 5 → 2 → 5 indefinitely. The instruction mov r1, r0 is never executed due to the branch.

Debugging: Observing PC Changes with GDB

(gdb) target remote :1234
(gdb) b _start
(gdb) b foo
(gdb) display/i $pc
(gdb) c
(gdb) si

display/i $pc is useful for watching how the PC changes step-by-step. You can clearly see the PC jump directly to the label when executing b foo.

Conclusion

In this post, we explored the basic unconditional branch instruction B in ARMv4. In the next post, we will look at BL, the instruction used for function calls. BL automatically stores the return address in the Link Register (LR), making it essential for implementing function calls.
